AIHUG090Z Humidifier

Make – Advance

  Model

     AIHUG060Z

Humidification Capacity

10 Kg/h

Power Supply

220VAC/50HZ

Work Temperature

5-45 ℃

Volume of water tank

16 L

Power Input (w)

600 W

Humidity control

10% - 95%

Noise Level

< 49 dB

Control precision

±3%RH

Mist outlet

110mm (one PVC pipe outlet)

Control mode

Automatically control, humidity display

Way of water-

In automatic

Protection measure

Lack water protection,
overflow protection

Air Volume

200 m3/h

Control

Humidity/time

Water Quality Required

Pure RO water

Cleaning Frequency

Once in a week

Net Weight

30 Kgs.

Gross Weight

31.5 Kgs.

Product Size (W X D X H) in mm

310 X 760 X 450

Package Dimension (W X D X H) in mm

330 X 780 X 480

FEATURES

  • • Humidity Indicator & Intelligent controller.
  • • Size of water mist 1-6
  • • Independent Humidification System
  • • Lowest energy consumption in its category
  • • No condensation due to very fine water particle size
  • • Easy to install
  • • No Structural modifications required
  • • Negligible maintenances, simplified even further due to portability of unit.
  • • High grade engineering plastic & GI powder coated components ensure corrosion free performance
  • • Using integrated ultrasonic atomizer, can change the atomizing piece, be convenient to maintain.
  • • Automatic/Manual intake mode can be chosen, with water level detection device and overflow protection, can automatically shut-down when lack of water.
  • • The droplet diameter is very small, only 1-5µm.
  • • Uniformity humidification, the maximum humidity up to 99%.

Advance Ultrasonic industrial humidifier utilizes ultrasonic oscillator to the water surface under the action of cavitation’s, form ultrafine particles with the diameter less than 10 um so that the water spray to form a more balanced humidity field mist particles, and the flow of air to heat exchange, to achieve the purpose of increasing humidity..
