AIDR600 Dehumidifier

Make – Advance

Model

AIDR600

Dehumidifying capacity(20°C,60%)

3kg/h

Process air flow

580m3/h          (341CFM)

Reactivation air flow

200m3/h           (117CFM)

Applied Temperature

-10°C-40°C

Max power

4.5KW

Power rating

3.8KW

Voltage

220V

Current

20A

Dimension

678*470*1060mm

Applying space

40-70m2

Quality/Safety Approval

ISO/GS/CE/ROHS/EMC

Features:

  • Accurate computer control system
  • Proflute Rotor, imported from Sweden, washable
  • Silence, economical, saving, and easy operation
  • Cleanable air filters helps improve the quality of air being circulated through the system at the processing air entrance &reactivation air entrance
  • Easy installation and checking.
  • CNC machining structure process
  • Efficient absorption silica gel wheel
  • Industrial flange for easy operation
  • Leakage protection safeguard for electrical motor; heater and the drive wheel
  • Unique seal design; Reduces air leakage
  • Dynamic balance design, ensures stable operation while moving
  • Able to operate in a wide range of temperatures from 10˚C + 50˚C heat
  • The design is in line with the requirements of IEC protection
  • Electrical design in accordance with international standards
Note:. The height of application are is 3 meter, the testing conditions in the lab is: ;T+20 deg C, RH 60%
