AIHUG120Z



AIHUG120Z Humidifier

Make – Advance



Model

AIHUG120Z

Humidification Capacity

20 Kg/h

Water Tank in Ltrs.

23 L

Voltage/Cycle

220VAC/50HZ

Work Temperature

5-45℃

Rated power

1200W(220V)

Humidity control

10% - 95%

Control precision

±3%RH

Noise Level

< 49 dB

Mist outlet

110mm (two PVC pipe outlet)

Control mode

Automatically control, humidity display

Way of water-

In automatic

Protection measure

Lack water protection,
overflow protection

Air Volume

350 m3/h

Control

Humidity/time

Water Quality Required

Pure RO water

Cleaning Frequency

Once in a week

Net Weight

49 Kgs.

Gross Weight

51 Kgs.

Product Size (W X D X H) in mm

450 X 775 X 500

Package Size (W X D X H) in mm

475 X 800 X 525

FEATURES

  • • Humidity Indicator & Intelligent controller.
  • • Size of water mist 1-6
  • • Independent Humidification System
  • • Lowest energy consumption in its category.
  • • No condensation due to very fine water particle size.
  • • Easy to install.
  • • No Structural modifications required.
  • • Negligible maintenances, simplified even further due to portability of unit.
  • • High grade engineering plastic & GI powder coated components ensure corrosion free performance
  • • Using integrated ultrasonic atomizer, can change the atomizing piece, be convenient to maintain.
  • • Automatic/Manual intake mode can be chosen, with water level detection device and overflow protection ,can automatically shut-down when lack of water.
  • • The droplet diameter is very small ,only 1-5um.
  • • Uniformity humidification, the maximum humidity up to 99%.

Advance Ultrasonic industrial humidifier utilizes ultrasonic oscillator to the water surface under the action of cavitation’s, form ultrafine particles with the diameter less than 10 um so that the water spray to form a more balanced humidity field mist particles, and the flow of air to heat exchange, to achieve the purpose of increasing humidity..
